Suntec® 40 Gallon Tube Solar Water Heater

Suntec® solar water heaters 40 gallon tubes are easy to install and provide decades of hot water. These low maintenance units deliver continuous hot water supply in all weather conditions straight into your homes while providing impressive energy savings at no compromise to your comfort.

Key Features:

Super Energy Saver

Saves up to 40% or more on your electric bill when compared to electric water heaters.

Pressurized Systems

Delivers constant water flow for your comfort

Passive Solar Tracking Technology

Provides 20% more solar exposure than regular solar water heaters.

Adjustable Galvanized Steel Frame Structure

Offers durable and versatile mounting capabilities for both slopes and flat roofs.

High Density Polyurethane Foam Insulated Tank

Provides up to 72 hours of storage of hot water in the absense of sunlight

Auxiliary Electric Heater & Controller (Optional)

Food Grade Stainless steel inner tank

Provides safe and healthy water storage

High efficiency state of the art vaccum tube absorber and heat pipe transfer system

Each replaceable independent

Technical Specifications

TANK A9H-12

Tank Capacity( net) 150L

Inner tank dia.370mm,

Outer tank dia.460mm,

Galvanized steel coated PVDF

Length 1520mm

Insulation high density

polyurethane foam

Working Pressure 7 bar

TUBES

Number of tubes 12

Type Vacuum tube+copper heat pipe+al fin

Tube length & Dia 1800mm, dia.58mm

Glass material Borosilicate

Coating ALN/AOM-SS/CU

Glass thickness 1.6mm

FRAME

Material Galvanized steel 1.5mm

Application Slope / Flat Surfaces

EFFICIENCY

Absorptivity Coefficient 95%

OTHER

Aperture area 2.16m2

System Gross Weight 76kgs

Certification Solar Keymark ( EN 12976-2:2006)

SPARE PARTS

Standard T/P valve, magnesium bar

Option Electric heater, controller
